024501 Cylinder

This component is constructed from durable materials such as cast iron or machined stainless steel, providing resistance to wear, corrosion, and chemical exposure. The 024501 Cylinder measures approximately 150 mm in length with an 80 mm outer diameter, and it features a bore diameter of 50 mm. The stroke length is 100 mm, allowing for precise fluid displacement. The cylinder weighs approximately 1.2 kg, which facilitates straightforward installation and maintenance procedures.

Manufactured to tight tolerances of ±0.02 mm, the 024501 Cylinder ensures proper fit and seal integrity in pump assembly. Its surface finish is standardized at Ra 0.8 micrometers to promote smooth operation and minimize wear. Suitable for pump models with operating pressures up to 10 bar (145 psi) and temperatures ranging from -20°C to +80°C, this cylinder maintains performance across various industrial applications.

Key features include a robust design for long-term reliability, compatibility with chemical transfer, petroleum product handling, and industrial fluid applications, as well as suitability for use in facilities seeking to optimize pump uptime and precision fluid metering. The 024501 Cylinder is an essential component for maintaining peak pump performance and minimizing downtime.

The product package includes the 024501 Cylinder itself, along with installation instructions and a serial number for warranty registration. Additional pump components, mounting hardware, and tools are not included and must be sourced separately.

Care instructions involve regular inspection for signs of surface wear or corrosion, cleaning with compatible non-abrasive solutions, and replacement if damage or excessive wear occurs. The manufacturer provides a standard 12-month warranty covering manufacturing defects for the 024501 Cylinder.
