KI Pumps & Systems, Inc.  |  SKU: 793603

793603 FLANGE-3/4 NPT

$ 224.10 $ 249.00

793603 FLANGE-3/4 NPT Ships in 1-2 Weeks or Special Order

Delivery and Shipping

We ship in stock items same day. If it needs to be ordered we will ship it out to you the day it arrives.

If you have any questions you can reach us at (262) 646.4500 or click here

Description

The 793603 FLANGE-3/4 NPT is a highly durable flange component manufactured by Blackmer, a globally recognized brand in pump technology. This flange is designed to secure a 3/4 inch National Pipe Thread (NPT) connection, ensuring a tight, reliable seal within fluid transfer systems. Constructed from corrosion-resistant materials, the flange maintains mechanical integrity under various operating conditions, making it suitable for demanding industrial environments.

Dimensions of the 793603 FLANGE-3/4 NPT include an outer diameter of approximately 4.4 inches (112 mm), with a thickness of roughly 0.3 inches (8 mm). The threaded connection conforms precisely to NPT standards, enabling easy compatibility with compatible piping and fittings. The flange features a flat mounting surface with four bolt holes evenly spaced at 2.8 inches (71 mm) apart, facilitating secure attachment to pump components or pipelines.

Key features of the 793603 FLANGE-3/4 NPT include:

  • Material: Aluminum alloy, offering a balance of strength and corrosion resistance
  • Thread type: 3/4 inch NPT internal thread for secure pipe connection
  • Bolt hole configuration: Four evenly spaced bolt holes for stable mounting
  • Standard compliance: Meets industry specifications for pipe fittings and flange connections
  • Operating environment: Suitable for use in water, oil, and chemical transfer systems

This flange is ideal for use in fluid handling and piping systems requiring a reliable 3/4 NPT connection. It is suitable for applications such as pump installations, chemical processing, and industrial fluid transfer where durable and precise fittings are necessary. The 793603 FLANGE-3/4 NPT is an essential component for technicians, engineers, and maintenance professionals seeking high-quality pump accessories from a trusted brand.

Included in the package is the flange itself; no additional fittings or hardware are supplied. Proper installation should follow manufacturer specifications to ensure optimal performance and leak-free connections.

Care instructions involve regular cleaning to prevent corrosion and easy replacement if signs of wear or damage occur. The flange does not require special maintenance beyond routine inspection. For longevity, avoid exposure to aggressive chemicals beyond specified limits, and follow standard storage practices when not in use.

Our Collections

Frequently Asked Questions

What are the main benefits of using the 793603 FLANGE-3/4 NPT in industrial piping systems?
The 793603 FLANGE provides a reliable, corrosion-resistant connection suitable for water, oil, and chemical systems, ensuring a secure, long-lasting seal in demanding environments. Its precise NPT threading and sturdy design help prevent leaks and maintain system integrity.
How do I ensure proper installation of the 793603 FLANGE for a leak-free connection?
Proper installation involves aligning the flange accurately with compatible piping, tightening the four bolt holes evenly to ensure a secure fit, and adhering to manufacturer torque specifications to prevent leaks. Regular inspection and maintenance also help ensure longevity.
What materials is the 793603 FLANGE made of, and how does that affect its durability?
The 793603 FLANGE is made from aluminum alloy, which offers a good balance of strength and corrosion resistance, making it suitable for various industrial environments. This material choice enhances durability and extended service life.
