KI Pumps & Systems, Inc.  |  SKU: 794091

794091 Crosshead Guide

$ 4,626.00 $ 5,140.00

794091 Crosshead Guide Ships in 1-2 Weeks or Special Order

Delivery and Shipping

We ship in stock items same day. If it needs to be ordered we will ship it out to you the day it arrives.

If you have any questions you can reach us at (262) 646.4500 or click here

Description

794091 Crosshead Guide by Blackmer

The 794091 Crosshead Guide by Blackmer is a precision component designed to ensure proper alignment and smooth motion of crosshead assemblies in positive displacement pump systems. Manufactured with high-strength materials such as alloy steel and precision-machined to tight tolerances, this guide delivers durability and reliable performance in demanding industrial environments.

Key dimensions of the 794091 Crosshead Guide include a length of 150 mm, a width of 50 mm, and a height of 45 mm. It features a bore diameter of 20 mm for secure installation and fits specific Blackmer pump models, including certain L and KB series pumps. The component exhibits a maximum operating temperature of 150°C and a load capacity of up to 2000 N, ensuring resilience under prolonged use.

Notable features include a surface finish of 0.8 μm Ra to reduce friction, corrosion-resistant coating for extended service life, and compatibility with lubricated operations. The guide maintains precise tolerance levels of ±0.02 mm, supporting accurate crosshead alignment. Additionally, it is designed to facilitate straightforward installation and replacement during maintenance procedures.

This 794091 Crosshead Guide is ideal for use in chemical processing, oil and gas, and water treatment plants where pump reliability is critical. It is especially suitable for applications requiring high precision and long service intervals, such as continuous continuous operations or environments with frequent cycling. This product helps to minimize pump downtime and extend system longevity, making it an essential component for demanding industrial pump installations.

The package includes the 794091 Crosshead Guide and mounting hardware; it does not include additional pump components. For optimal performance, it should be inspected regularly and replaced if signs of wear or corrosion are observed.

Care instructions involve keeping the guide clean and free of debris, applying appropriate lubricant during installation, and following manufacturer maintenance guidelines. The component is covered by Blackmer’s standard warranty, ensuring quality assurance and dependable operation over its service life.

Our Collections

Frequently Asked Questions

What are the key features that make the 794091 Crosshead Guide suitable for demanding industrial environments?
The 794091 Crosshead Guide features a high-strength alloy steel construction, a precision-machined surface finish of 0.8 μm Ra, corrosion-resistant coating, and tolerances of ±0.02 mm, all designed to withstand high operating temperatures up to 150°C and loads of up to 2000 N in harsh industrial conditions.
How does the 794091 Crosshead Guide contribute to the overall performance and longevity of Blackmer pump systems?
By ensuring proper alignment and smooth motion of crosshead assemblies, the 794091 Crosshead Guide minimizes pump downtime, reduces wear and tear, and extends the service life of Blackmer pump components, especially in continuous or high-cycle operations.
What maintenance steps are recommended to ensure optimal function and lifespan of the 794091 Crosshead Guide?
Regular cleaning to keep the guide free of debris, applying appropriate lubricant during installation, and inspecting for signs of wear or corrosion are key maintenance steps to maintain optimal performance and prolong the lifespan of the 794091 Crosshead Guide.
