871085 Adjustable Bracket, Mounting Ring, and Torque Arm

Introducing the 871085 Adjustable Bracket, Mounting Ring, and Torque Arm for HRB & HRC Pumps

The 871085 Adjustable Bracket is a high-strength, industrial-grade component designed to facilitate precise mounting of HRB & HRC pump assemblies. This set includes a durable mounting ring and a torque arm, engineered to ensure accurate alignment, reduce vibration, and manage reaction forces during pump operation. Constructed from corrosion-resistant materials such as ductile iron or steel, the bracket assembly provides long-term durability under demanding industrial conditions.

Dimensions and compatibility:

• The adjustable bracket measures approximately 150 mm in length with multiple mounting bolt holes allowing for fine positional adjustments. The mounting ring has an inner diameter compatible with standard pump shafts, typically around 100 mm, ensuring secure fitment.
• The torque arm length varies between 250 mm to 350 mm, providing leverage to effectively control drivetrain reaction forces.
• The entire assembly is designed for compatibility with Blackmer HRB & HRC pump models, supporting pumps with mounting flanges aligned to industry standards.

Key features:

• Provides precise concentric alignment of the drive components for optimal power transfer
• Includes an adjustable mounting bracket permitting fine-tuning during installation and maintenance
• Features a robust mounting ring that secures the pump shaft and minimizes misalignment risks
• Equipped with a torque arm to manage and redistribute reaction forces, extending component lifespan
• Constructed from industrial-grade materials capable of withstanding high loads, vibration, and thermal cycles
• Facilitates straightforward installation, inspection, and routine servicing

Use cases for the 871085 Adjustable Bracket include:

• Aligning and mounting HRB & HRC pumps in chemical processing, water treatment, and fluid transfer applications
• Installing new pump systems where precise alignment and vibration control are critical for operational efficiency
• Performing maintenance or retrofit upgrades on existing pump installations with minimal downtime
• Designed for budget-conscious facilities requiring reliable, reusable mounting hardware that balances performance and cost

The set ships complete with the adjustable bracket, mounting ring, and torque arm. Not included are tools required for installation such as wrenches or torque wrenches. Proper handling and torqueing procedures should be followed for installation and maintenance.

Care instructions include regular inspection of mounting bolts and torque arm alignment, cleaning with suitable non-abrasive solutions, and adherence to manufacturer’s warranty guidelines. For optimal longevity, scheduled inspections and proper torque settings are recommended at periodic intervals.
